10x10x0.45 mm  InSb  wafer   (P type, Ge doped)

•  Size:                      5x5x0.45 mm
• Orientation            <100> /-0.5^o  with two reference flats
•  Polishing:            two sides polishd
• Packing:               Sealed under nitrogen with single wafer comtainer  in 1000 class clean room

Properties

• Properties

  • Growth method                                                 LEC
  • Orientation                                                         (100)   /- 0.5 ^o
  • Orientation Flat                                                 N/A
  • Doping                                                                Ge
  • Conductivity type                                               P Type
  • Carrier Concentration                                     1.35x10^15/cc @77K
  • Mobility                                                               6300  cm²/Vs
  • EPD                                                                    <=200  / cm ²
  • Resistivity:                                                    7.34E-1  ohm.cm
