D19 1/2" 10mm BiHex Socket

• Acc. to DIN 3124, ISO 2725-1
• Square drive as per DIN 3120 - C 12,5, ISO 1174, with ball retention groove
• Manually operated, with non-slip cross knurling
• Chrome vanadium steel 31CrV3, ground, chrome-plated
• * not standardised

Specifications

• Drive mount, square [metric]: 12,5mm
• Drive connector square [inch]: 1/2"
• Standard: DIN 3120 – C 12,5 ISO 1174 DIN 3124
• Insert-Ø 1: 15,5mm
• Insert-Ø 2: 22,5mm
• Working length: 38,0mm
• Operating depth: 13,5mm
• Material: Chrome-vanadium steel 31CrV3
• Surface: polished, chrome-plated
• Width across flats 1 [mm]: 10
